WW-P-541/4B
TABLE III:
Stainless steel lavatory identification (300
series S P N ) .
SPN
Nominal size (inches)
Lavatory type
300
20 x 18
self-rimming with ledge,
rectangular, See figure 1
301
18 in diameter
Self-rimming with ledge,
302
19 in diameter
round. See figure 2
303
20 x 17
Self-rimming with ledge,
oval. See fiqure 3
Porcelain enameled formed steel lavatory identification (400 series
TABLE IV.
SPN) .
SPN
Nominal size (inches)
Lavatory type
400
19 X 16
Flat rim with ledge,
401
20 X 18
rectangular. See-figure 1
402
20 x 18
Self-rimming with ledge,
rectangular?
See figure 1
403
18 in diameter
rim with ledge, round.
Flat
404
19 in diameter
See figure 2
405
19 X
16
Flat rim with ledge, oval.
406
20 x 17
See figure 3
407
Self-rimming with ledge,
1 8 in diamter
408
19 in
diameter
round See figure 2
20 x 17
409
Self-rimming with
ledge, oval.
_ See fiqure 3
Plastic lavatory
identification (500 series SPN).
TABLE V.
Nominal size (inches)
SPN
Lavatory type
500
18 in diameter
Self-rimming with ledge,
round. See figure 2
20 x 17
501
Self-rimning: with ledge;
oval, See fiqure 3
2.
APPLICABLE" DOCUMENTS
2.1 Latest issue of WW-P-541/GEN and documents referenced therein.
3.
REQUIREMENTS
3.1 Materials and components.
conform, as
Materials and components shall
basic speci-
applicable, to ANSI A112.19.LM through A112.19.4, 2124.3, and the
`W-P-541/GEN.
fication
4
