WW-P-541/4B
August 1, 1980
SUPERSEDING
Fed. Spec. WW-P-541/4A
October 12, 1971
PLUMBING FIXTURES (LAVATORIES)
(DETAIL SPECIFICATION)
This specification forms a part of the latest issue of
Federal Specification WW-P-541/GEN.
SCOPE AND CLASSIFICATION
1.
Scope. This specification covers specific requirements for lavatories.
1.1
Classification.
1.2
1.2.1 Types. Lavatories furnished under this specification sheet shall be
of the types indicated in tables I through V.
1.2.2 Definitive part number (DPN). Lavatories covered by this
specification shall be identified by a DPN. This part number is intended for
cataloging and ordering purposes; it is not intended for surface printing on
the lavatories. The DPN shall consist of the Federal specification symbol
plus the specification part number (SPN) (see tables I through V). The DPN
shall be written as indicated below (see 6.1 and 6.4).
wwP541/4
DPN
Specification sheet identification
for fixture required
FSC 4510
