WW-P-541/3B
August 1, 1980
SUPERSEDING
Fed. Spec. WW-P-541/3A
October 12, 1971
FEDERAL SPECIFICATION SHEET
PLUMBING FIXTURES (BATHTUBS)
(DETAIL SPECIFICATION)
This specification forms a part of the latest issue of
Federal Specification WW-P-541/GEN
1.
SCOPE AND CLASSIFICATION
1.1
This specification covers specific requirements for bathtubs.
Scope.
1.2 Types. Bathtubs furnished under this specification sheet shall be of
the types indicated in tables 1, II, and III.
1.2.2 Definitive part number (DPN). Bathtubs covered by this speci-
fication shall be identified by a DPN. This part number is not intended for
surface printing on the bathtubs. The DPN shall consist of the Federal
specification symbol plus the specification part number (SPN) (see tables 1,
II, and 111). The DPN shall be written as indicated below (see 6.1 and 6.4).
DPN
WWP541/3
XXXXX
Specification sheet identification
for fixture required
I
SPN
I
Table I.
Enameled cast iron bathtub identification (100 series (SPN)) 1/.
Bathtub
Drain
Nominal
Front
type
RN LH
size (inches)
SPN
Extended/straight
Corner
RH
60X16
Straight
Cl100
Corner
LH
60X16
CI102
Straight
Corner
60x16
RN
Extended
CI103
Corner
60X16
LH
CI104
Extended
Recess
RH
54X16
Straight
CI105
Recess
LH
CI106
54X16
Straight
Recess
RN
54X16
CI107
Extended
CI108
Recess
LH
Extended
54X16
Recess
RH
60x16
Straight
CI109
Recess
LH
60x16
Straight
CI11O
Recess
RH
60X16
Extended
CI111
Recess
LH
60X16
CI112
Extended
Recess
RN
66X16
Straight
CI113
1/ See figure 1 for all items in table I.
FSC 4510
